- Brand Name: Fimonda
- Origin: Mainland China
- Material: Metal
- Tool Supplies: Assembled class
- Upgrade Parts/Accessories: Chassis Frame
- RC Parts & Accs: AXLE
- Size: 295-343mm Wheelbase
- Use: Vehicles & Remote Control Toys
- Quantity: 1 pcs
- Technical parameters: Value 2
- Model Number: RUN-80
- Remote Control Peripherals/Devices: RC LC80 Chassis
- For Vehicle Type: Cars
- Four-wheel Drive Attributes: Assemblage
- Wheelbase: Screws
The cart will find it's way round the hill when it get there, where there is a way, there is LC80.
Specifications
Wheelbase: 319MM (Adjustable Maximum 343MM, Minimum 295MM)
Size
Front Width: 74MM / 2.91"
Rear Width: 118MM / 4.65"
Axle Width: 171MM / 6.73" (Not Included Hex)
Total Length: 519MM / 20.43"
Weight: 2.7KG
Material: Metal
Scale: 1/10
Function: Off-road
Drive: Electronic Drive (Fit 540 motor, recommend 21T)
Requires Assembly
Features
FRAME RAIL CHASSIS：
• Ultra scale looks, and superior quality and craftsmanship
• Made of durable steel
• Double C-channel structure and cross braces improve chassis rigidity (torsional stiffness)
• More additional holes have been added to the frame rails for making wheelbase (adjustments (Maximum 343MM, Minimum 295MM)
TRANSMISSION:
• Front-Mounted Moter (NOTE: motor not included.)
• Realistic, detailed transmission housing in a cast metal look
• All metal internal gears
• 3 output shaft, Forward/Reverse, linear + inertial output
• Realistic scale cooling fan(Equipped with mini motor and belt drive)
• Adjustable installation
• Gear ratio 1:24.8
AXLES:
• Die cast zinc alloy housing
• Ackermann steering, Up to 45 degrees
• Front / Rear panhard bar
• Reverse transmission, smooth action for an efficient drivetrain
• Hardened steel helical gear set
• Compact yet durable design
• Gear ratio 1:3.6
SHOCKS:
• Separate design, spring + shock damping
• Compact yet durable design
• Organ style cover, Highly detailed and super realistic
DRIVE SHAFTS:
• The front and rear drive shafts feature an updated design for added strength
• Added carbon hardened steel material which reduces flex and fatigue
• A hexagon splined slideroffers super travel length and super smooth operation
SUSPENSION
The link rod is made out of heat-treated carbon steel to withstand extreme conditions and the black rubber boot protects the link rod from the elements for even more durability while adding to the scale look.
Required to Complete (not included):
Wheels
Tires
Body
Motor (Recommend 540 21T motor )
Electronic Speed Controller "ESC"
Radio and Receiver (3 Channels or more)
Servo
Battery (Consult your "ESC" manual)
Charger (Consult your battery guide)
